Use the Removable Drives menu (BIOS Menu 21) to specify the boot sequence of the
available USB devices. When the menu is opened, the USB devices connected to the
system are listed as shown below:
1st Drive [1
st
USB]
2nd Drive [2
nd
USB]
NOTE:
Only the drives connected to the system are shown. For example, if only
one USB device is connected only “1st Drive” is listed.
The boot sequence from the available devices is selected. If the “1st Drive” option is
selected a list of available USB devices is shown. Select the first USB device the system
boots from. If the “1st Drive” is not used for booting this option may be disabled.
