KINO-9652 Mini-ITX SBC
Page 131
Disabled DEFAULT
The real time clock (RTC) cannot generate a wake
event
Enabled
If selected, the following appears with values that
can be selected:
RTC Alarm Date (Days)
RTC Alarm Time
After setting the alarm, the computer turns itself on
from a suspend state when the alarm goes off.
6.4 PCI/PnP
Use the PCI/PnP menu (BIOS Menu 17) to configure advanced PCI and PnP settings.
WARNING!
Setting wrong values for the BIOS selections in the PCIPnP BIOS menu
may cause the system to malfunction.
