KINO-9652 Mini-ITX SBC
Page 93
onboard connectors. See Figure 5-18.
Figure 5-18: Dual USB Cable Connection
Step 4: Attach the bracket to the chassis. The USB 2.0 connectors are attached to a
bracket. To secure the bracket to the chassis please refer to the installation
instructions that came with the chassis.Step 0:
5.7 External Peripheral Interface Connection
The following external peripheral devices can be connected to the external peripheral
interface connectors.
Audio devices
RJ-45 Ethernet cables
USB devices
VGA monitor
Serial port devices
Mouse and keyboard
