KINO-9652 Mini-ITX SBC
Page 83
Jumper Settings: See Table 5-4 and Table 5-5
Jumper Location: See
Figure 5-10
The COM port Pin 9 Setting jumpers (JP1 and JP2) configure pin 9 on COM 1, COM 2,
COM 3 and COM 4 as either a +5V, +12V power source or as a ring-in (RI) line. The COM
port Pin 9 Setting jumpers selection options are shown in
Table 5-4 and Table 5-5.
JP1 Description
Short 1 – 3 COM 1 RI Pin use +12V
Short 3 – 5 COM 1 RI Pin use +5V
Short 5 – 7 COM 1 RI Pin use +5V
Short 7 – 9 COM 1 RI Pin use RI Default
Short 2 – 4 COM 2 RI Pin use +12V
Short 4 – 6 COM 2 RI Pin use +5V
Short 6 – 8 COM 2 RI Pin use +5V
Short 8 – 10 COM 2 RI Pin use RI Default
Table 5-4: COM 1/2 Pin 9 Setting Jumper Settings
JP2 Description
Short 1 – 3 COM 3 RI Pin use +12V
Short 3 – 5 COM 3 RI Pin use +5V
Short 5 – 7 COM 3 RI Pin use +5V
Short 7 – 9 COM 3 RI Pin use RI Default
Short 2 – 4 COM 4 RI Pin use +12V
Short 4 – 6 COM 4 RI Pin use +5V
Short 6 – 8 COM 4 RI Pin use +5V
Short 8 – 10 COM 4 RI Pin use RI Default
Table 5-5: COM 3/4 Pin 9 Setting Jumper Settings
The COM port Pin 9 Setting jumper locations are shown in Figure 5-10 below.
