KINO-9453 Mini-ITX Motherboard
Page 71
Figure 5-12: LVDS Screen Resolution Selection Jumper Pinout Locations
5.4.6 LVDS Voltage Selection
WARNING:
Permanent damage to the screen and KINO-9453 may occur if the
wrong voltage is selected with this jumper. Please refer to the user
guide that cam with the monitor to select the correct voltage.
Jumper Label: JP4
Jumper Type:
4-pin header
Jumper Settings: See
Table 5-8
Jumper Location: See
Figure 5-13
