KINO-9453 Mini-ITX Motherboard
Page 52
4.3.7 USB Connector
CN Label: LAN/USB1 and LAN/USB2
CN Type:
USB port
CN Location: See
Figure 4-14
CN Pinouts: See
Table 4-21
USB devices can be connected directly to the USB connectors on the rear panel.
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VCC 5 VCC
2 USBD0- 6 USBD1-
3 USBD0+ 7 USBD1+
4 GND 8 GND
Table 4-21: External USB Connector Pinouts
