KINO-9453 Mini-ITX Motherboard
Page 37
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GND 20 (KEY)
21 DRQ 22 GND
23 IOW# 24 GND
25 IOR# 26 GND
27 CHRDY 28 GND
29 DACK 30 GND
31 INTERRUPT 32 N/C
33 SA1 34 P66DET
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GND
Table 4-6: IDE Connector Pinouts
4.2.5 LCD Backlight Connector
CN Label: CN1
CN Type:
6-pin header (1x6)
CN Location: See
Figure 4-6
CN Pinouts: See
Table 4-7
The LCD backlight connector is for the LCD inverter connection.
