KINO-9453 Mini-ITX Motherboard
Page 32
4.1.3 External Interface Panel Connectors
Table 4-2 lists the rear panel connectors on the KINO-9453. Detailed descriptions of these
connectors can be found in Section
4.3.
Connector Type Label
Audio connector Audio jack AUDIO
Ethernet connector RJ-45 LAN/USB1
Ethernet connector RJ-45 LAN/USB2
Keyboard and mouse connector PS/2 connector KBMS1
RS-232 serial port connector Male DB-9 COM1
RS-232 serial port connector Male DB-9 COM2
USB ports USB port LAN/USB1
USB ports USB port LAN/USB2
VGA port connector Female DB-15 VIDEO
DVI connector DVI connector VIDEO
Table 4-2: Rear Panel Connectors
4.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. This section has complete descriptions of
all the internal, peripheral connectors on the KINO-9453.
4.2.1 Fan Connectors
CN Label: CPU_FAN1, NB_FAN1 and SYS_FAN1
CN Type:
3-pin header
CN Location: See
Figure 4-2
