KINO-9453 Mini-ITX Motherboard
Page 27
1 SATA power cable
(P/N: 32100-088600-RS)
1 Mini jumper Pack
1 Quick installation guide
1 Utility CD
1 I/O shielding
Table 3-1: Package List Contents
3.3.2 Optional Items
NOTE:
The items listed in this section are optional items that must be ordered
separately. Please contact your KINO-9453 vendor, distributor or
reseller for more information or, contact IEI directly by sending an email
to
sales@iei.com.tw.
The following optional items are available for the KINO-9453.
