KINO-9453 Mini-ITX Motherboard
Page 26
3.3 Unpacking Checklist
NOTE:
If some of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the KINO-9453 from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to
sales@iei.com.tw.
3.3.1 Package Contents
The KINO-9453 is shipped with the following components:
Quantity Item and Part Number Image
1 KINO-9453
1 Dual RS-232 Cable
(P/N:32200-028401-RS)
1 IDE cable
(P/N: 32200-008800-RS)
2 SATA cables
(P/N: 32000-0628000-RS)
