KINO-9453 Mini-ITX Motherboard
Page 22
2.9 Environmental and Power Specifications
2.9.1 System Monitoring
Three thermal inputs on the KINO-9453 Super I/O Enhanced Hardware Monitor monitor
the following temperatures:
System temperature
Power temperature
CPU temperature
Eight voltage inputs on the KINO-9453 Super I/O Enhanced Hardware Monitor monitor the
following voltages:
CPU Core
+2.5V
+3.30V
+5.00V
+12.0V
GMCH (1.5V)
1.05V
5VSB
VBAT
The KINO-9453 Super I/O Enhanced Hardware Monitor also monitors the following
voltages internally:
VBAT
The KINO-9453 Super I/O Enhanced Hardware Monitor also monitors the following fan
speeds:
CPU Fan speed
The values for the above environmental parameters are all recorded in the BIOS
Hardware Health Configuration menu.
