2.6.5 Intel
®
ICH7-M PCI Interface
The PCI interface on the ICH7-M is compliant with the PCI Revision 2.3 implementation.
Some of the features of the PCI interface are listed below.
 PCI Revision 2.3 compliant
 33 MHz
 5 V tolerant PCI signals (except PME#)
 Integrated PCI arbiter supports up to seven PCI bus masters
2.6.6 Intel
®
ICH7-M Real Time Clock
256 bytes of battery backed RAM is provided by the Motorola MC146818A real time clock
(RTC) integrated into the ICH7-M. The RTC operates on a 3V battery and 32.768 KHz
crystal. The RTC keeps track of the time and stores system data even when the system is
turned off.
2.6.7 Intel
®
ICH7-M SATA Controller
The integrated SATA controller on the ICH7-M Southbridge supports two SATA drives on
the KINO-9453 with independent DMA operations. SATA controller specifications are listed
below.
 Supports two SATA drives
 Supports 1.5 Gb/s data transfer speeds
 Supports Serial ATA Specification, Revision 1.0a
2.6.8 Intel
®
ICH7-M USB Controller
Up to eight high-speed, full-speed or low-speed USB devices are supported by the
ICH7-M on the KINO-9453. High-speed USB 2.0, with data transfers of up to 480 MB/s, is
enabled with the ICH7-M integrated Enhanced Host Controller Interface (EHCI) compliant
host controller. USB full-speed and low-speed signaling is supported by the ICH7-M
integrated Universal Host Controller Interface (UHCI) controllers.
