KINO-9453 Mini-ITX Motherboard
Page 13
Family sSpec# CPU Speed Processor # Bus Speed Mfg Tech Stepping Cache Size
SL9SQ 1.66 GHz T5500 667 MHz 65 nm B2 2 MB
SL8VT 2 GHz T2500 667 MHz 65 nm C0 2 MB Core™ Duo
SL9DN 1.66 GHz T2300E 667 MHz 65 nm C0 2 MB
Core™ Solo SL92X 1.83 GHz T1400 667 MHz 65 nm C0 2 MB
SL9VA 1.73 GHz 530 533 MHz 65 nm A1 1 MB
Celeron® M
SL9LF 1.86 GHz 440 533 MHz 65 nm D0 1 MB
Table 2-2: Supported Processors
2.5 Intel
®
945GME Northbridge Chipset
2.5.1 Intel
®
945GME Overview
The Intel
®
945GME Northbridge chipset has the Generation 3.1 Intel Integrated Graphics
Engine and the Intel
®
Graphics Media Accelerator 950 (Intel
®
GMA 950). The integrated
graphics and memory controller hub (GMCH) facilitates the flow of information primarily
between the following four interfaces:
 Front Side Bus (FSB)
 System Memory Interface
 Graphics Interface
 Direct Media Interface (DMI)
2.5.2 Intel
®
945GME Memory Support
WARNING:
Only DDR2 memory module can be installed on the KINO-9453. Do not
install DDR memory modules. If a DDR memory module is installed on
the KINO-9453, the KINO-9453 may be irreparably damaged.
