KINO-9453 Mini-ITX Motherboard
Page 6
Specification KINO-9453
Socket 479 Intel
®
Celeron® M FSB 533 MHz (socket M)
Front Side Bus
533 MHz or 667 MHz
System Chipset
Northbridge: Intel
®
945GME
Southbridge: Intel
®
ICH7-M
Memory
Two 240-pin 400 MHz, 533 MHz or 667 MHz DDR2 SDRAM
DIMMs supported (system max. 4 GB)
Display
CRT: Integrated in the Intel
®
945GME to support CRT
DVI: Integrated in the Intel
®
945GME by SDVO interface
LVDS: Dual channel 18-bit or 24-bit LVDS LCD panel
BIOS
AMI BIOS
Audio
Realtek ALC655 with AC’97 codec
LAN
Two Broadcom BCM5787M PCIe GbE controllers
COM
Three RS-232 serial ports (one internal, two external)
One RS-232, RS-422 or RS-485 serial port
USB2.0
Eight USB 2.0 devices supported
IDE
One 40-pin IDE connects to two Ultra ATA33/66/100 devices
SATA
Two 1.5 Gb/s SATA drives supported
Keyboard/mouse
Two PS/2 connectors support mouse and keyboard
connectivity
Watchdog Timer
Software programmable 1-255 sec. by super I/O
Power Supply
AT and ATX supported
Temperature
0ºC – 60ºC (32ºF - 140ºF)
Humidity (operating)
5%~95% non-condensing
