KINO-9453 Mini-ITX Motherboard
Page 5
2 x Serial port connectors
2 x SATA connectors
1 x SPDIF connector
2 x USB connectors
The KINO-9453 has the following external peripheral interface connectors on the board
rear panel
2 x Audio jacks
1 x VGA connector
2 x Ethernet connectors
2 x Keyboard/Mouse connectors
2 x Serial port connectors
1 x DVI connector
4 x USB 2.0 ports
The KINO-9453 has the following on-board jumpers:
AT/ATX power mode selection
Clear CMOS
COM3 mode selection (RS-232/422/485)
RS-422 or RS-485 termination resister
LVDS LCD voltage selection
LVDS screen resolution selection
1.2.3 Technical Specifications
KINO-9453 technical specifications are listed in Table 1-1. See Chapter 2 for details.
Specification KINO-9453
Form Factor
Mini-ITX
System CPU
Socket 479 Intel
®
Core™ 2 Duo Mobile
Socket 479 Intel
®
Core™ Duo
Socket 479 Intel
®
Core™ Solo
