ASF Support [Enabled]
Use the ASF Support BIOS option to control the system’s ability to connect to a remote
management server.
Disabled
The system will not communicate with a remote
management server.
Enabled DEFAULT
The Alert Standard Format (ASF) controller is activated
and can communicate with a remote management
server.
Audio Controller [AC`97 Audio Only]
The Audio Controller option allows selection of the audio controller to use.
AC`97 Audio
Only
The on-board AC’97 controller is enabled
Disabled
All audio controllers are disabled
OnBoard LAN1 (BCM5787M) [Enabled]
The OnBoard LAN1 (BCM5787M) option enables or disables the on-board LAN1.
Auto
The on-board LAN1 controller is automatically detected
and enabled
Enabled D
EFAULT
The on-board LAN1 controller is manually enabled
Disabled
The on-board LAN1 controller is manually disabled
On-board LAN2(BCM5787M) [Enabled]
The On-board LAN2(BCM5787M) option enables or disables the on-board LAN2.
Auto
The on-board LAN2 controller is automatically detected
