KINO-9453 Mini-ITX Motherboard
Page 135
PCI/IGD DEFAULT
Internal Graphics Mode Select [Enable, 8MB]
Use the Internal Graphic Mode Select option to specify the amount of system memory
that can be used by the Internal graphics device.
Disable
Enable, 1MB
1MB of memory used by internal graphics device
Enable, 8MB DEFAULT
8MB of memory used by internal graphics device
PEG Port [Auto]
Use the PEG Port option to enable or disable the PCI Express port.
Auto DEFAULT
The system automatically detects the PEG port.
Disabled
Installed PEG cards cannot function.
PEG Force X1 [Disabled]
Use the PEG Force x1 option to convert a PCI express X16 slot into a PCI express X1
slot.
Disabled DEFAULT
PCI express X16 slot runs in normal mode
Enabled
PCI express X16 slot runs in PCI express X1
mode
6.7.1.1 Video Function Configuration
Use the Video Function Configuration menu to configure the video device connected to
the system.
