KINO-9453 Mini-ITX Motherboard
Page 129
Disabled
PS/2 mouse support is disabled and prevented from
using system resources.
Enabled
Allows the system to use a PS/2 mouse.
Auto DEFAULT
The system auto-adjusts PS/2 mouse support.
Boot From LAN Support [Disabled]
Use the Boot From LAN Support option to enable the system to be booted from a remote
system.
Disabled DEFAULT
Cannot be booted from a remote system through the
LAN
Enabled
Can be booted from a remote system through the
LAN
6.5.2 Boot Device Priority
Use the Boot Device Priority menu (BIOS Menu 17) to specify the boot sequence from
the available devices. Possible boot devices may include:
1
st
FLOPPY DRIVE
HDD
CD/DVD
