KINO-9453 Mini-ITX Motherboard
Page 111
activity
Enabled
Wake event generated by PCI PME controller activity
Resume On RTC Alarm [Disabled]
Use the Resume On RTC Alarm option to specify the time the system should be roused
from a suspended state.
Disabled DEFAULT
The real time clock (RTC) cannot generate a wake
event
Enabled
If selected, the following appears with values that
can be selected:
RTC Alarm Date (Days)
System Time
After setting the alarm, the computer turns itself on
from a suspend state when the alarm goes off.
Resume On PCI-Express WAKE# [Enabled]
The Resume On PCI-Express WAKE# BIOS option specifies if the system is roused from
a suspended or standby state when there is activity on the PCI express port.
Disabled
Wake event not generated by PCI express activity
Enabled DEFAULT
Wake event generated by PCI express activity
6.3.7 Remote Access Configuration
Use the Remote Access Configuration menu (BIOS Menu 11) to configure remote
access parameters. The Remote Access Configuration is an AMIBIOS feature and
allows a remote host running a terminal program to display and configure the BIOS
settings.
