Serial Port3 IRQ [11]
Use the Serial Port3 IRQ option to select the interrupt address for serial port 3.
10
Serial port 3 IRQ address is 10
11 DEFAULT
Serial port 3 IRQ address is 11
Serial Port4 Address [2E8]
Use the Serial Port4 IRQ option to select the interrupt address for serial port 4.
Disabled
No base address is assigned to serial port 3
3E8
Serial port 4 I/O port address is 3E8
2E8 DEFAULT
Serial port 4 I/O port address is 2E8
2F0
Serial port 3 I/O port address is 2F0
2E0
Serial port 4 I/O port address is 2E0
Serial Port4 IRQ [10]
Use the Serial Port4 IRQ option to select the interrupt address for serial port 4.
10 DEFAULT
Serial port 4 IRQ address is 10
11
Serial port 4 IRQ address is 11
