Onboard USB 2.0 [Enabled]
Use the Onboard USB 2.0 option to en able or disable the chipset USB controller.
Enabled
(Default) Chipset USB 2.0 controller enabled
Disabled
Chipset USB 2.0 controller disabled
Onboard IDE [Enabled]
Use the Onboard IDE option to specify if the system uses the integrated primary IDE
channel or not.
Disabled
The primary IDE channel is not used.
Enabled
(Default) The primary IDE channel is used.
Memory Hole At 15M – 16M [Disabled]
Use the Memory Hole At 15M – 16M option to reserve memory space between 15MB
and 16MB for ISA expansion cards that require a specified area of memory to work
properly. If an older ISA expansion card is used, please refer to the documentation that
came with the card to see if it is necessary to reserve the space.
Disabled
(Default) Memory is not reserved for ISA expansion cards.
Enabled
Memory is reserved for ISA expansion cards.
5.4.1 Flat Panel Configuration
Use the Flat Panel Configuration menu to configure the screen resolution.
