IOWA-LX-600 Half-size CPU Card
Page 80
Video Memory Size [32 M]
Use the Frame Buffer Size option to specify the amount of memory allocated to the
integrated graphics proce ssor when th e system boots up. Configuration option s are.
Disable
8 M
16 M
32 M (Default)
64 M
128 M
254 M
Output Display [Panel & CRT]
Use the Output Display configuration to specify the display devices the system is
connected to. The Output Display options are:
Flat Panel
CRT
Panel & CRT (Default)
Onboard Audio [Enabled]
Use the Onboard Audio option to enable or disable the chipset codec.
Enabled
(Default) The onboard audio codec is enabled.
Disabled
The onboard audio codec is disabled.
Onboard USB 1.1 [Enabled]
Use the Onboard USB 1.1 option to en able or disable the chipset USB controller.
Enabled
(Default) Chipset USB 1.1 controller enabled
Disabled
Chipset USB 1.1 controller disabled
