IOWA-LX-600 Half-size CPU Card
Page 79
5.4 Advanced Chipset Features
Use the Advanced Chipset Features menu (6BIOS Menu 5) to change chipset
configuration options.
Phoenix - AwardBIOS CMOS Setup Utility
Advanced Chipset Features
CPU Frequency [366 MHz]
Memory Frequency [Auto]
Video Memory Size [ 32 M]
Output display [Panel & CRT]
> Flat Panel Configuration [Press Enter]
Onboard Audio [Enabled]
Onboard USB1.1 [Enabled]
Onboard USB2.0 [Enabled]
Onboard IDE [Enabled]
Memory Hole At 15M-16M [Disabled]
Item Help
Menu Level >
↑ ↓:Move Enter:Select +/-/PU/PD:Value F10:Save Esc:Exit F1:General Help
F5=Previous Values F6:Fail-Safe Defaults F7 Optimized Defaults
BIOS Menu 5: Advanced Chipset Features
CPU Frequency [366 MHz]
Use the CPU Frequency option to set the CPU frequency.
Memory Frequency [Auto]
Use the Memory Frequency option to set the frequency of the installed DRAM modules.
The Memory Frequency options are:
Auto (Default)
200MHz
266MHz
333MHz
