SATA Boot ROM Control [Disabled]
Use the SATA Boot ROM Contr ol option to config ure SATA IDE use in DOS mode.
Disabled
(Default) Disables SATA IDE use in DOS mode.
Enabled
Enables SATA IDE use in DOS mode.
Boot Device
Use the Boot Device options to select the order of the devices the system boots from.
There are three boot device configuration options:
First Boot Device [Default: HDD-0]
Second Boot Device [Default: SCSI]
Third Boot Device [Default: LS-120]
Using the default values, the system first looks for a FDD to boot from. If it cannot find an
FDD, it boots from a HDD. If both the FDD an d the HDD are unavail able, the syst em boots
from a LS-120 drive.
Boot Device configuration options are:
Floppy
LS120
HDD-0
SCSI
CDROM
HDD-1
ZIP100
USB-FDD
USB-ZIP
USB-CDROM
USB-HDD
LAN
Disabled
