IOWA-LX-600 Half-size CPU Card
Page 44
o When working with the IOWA-LX-600, make sure that it is disconnected
from all power supplies and that no electricity is being fed into the system.
Before and during the installation of the IOWA-LX-600 DO NOT:
Remove any of the stickers on the PCB board. These stickers are required for
warranty validation.
Use the product before verifying all the cables and power connectors are
properly connected.
Allow screws to come in contact with the PCB circuit, connector pins, or its
components.
4.3 Unpacking
When the IOWA-LX-600 is unpacked, please check all the unpacking list items listed in
Chapter 3 are indeed present. If any of the unpacking list items are not available please
contact the IOWA-LX-600 vendor resell er/vendor where the IO WA-LX-600 was purchased
or contact an IEI sales representative.
4.4 SO-DIMM Installation
NOTE:
Using incorrectly specified SO-DIMM may cause permanently damage
the IOWA-LX-600. Please make sure the purchased SO-DIMM
complies with the memory specifications of the IOWA-LX-600.
SO-DIMM specifications compliant with the IOWA-LX-600 are listed in
Chapter 2.
To install a SO-DIMM into a SO-DIMM socket, please follow the steps below and refer to
6Figure 4-1.
