3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
ATX power enable connector 3-pin wafer CN3
Audio connector 10-pin box header CN19
Backlight inverter connector 5-pin wafer CN7
Battery connector 2-pin wafer CN14
CompactFla sh® slot CF Type II slot CN28
DDR SO-DIMM socket 200-pin socket CN29
Digital I/O conne ctor 10-pin header CN16
Fan connector (CP U) 3-pin wafer CN8
Floppy disk connector 34-pin box header CN9
Front panel connector 10-pin header CN6
IDE connector 40-pin box header CN11
Infrared connector 5-pin header CN15
Keyboard and mouse connector 6-pin wafer CN25
Parallel port connector 26-pin box header CN17
Power connector (+12V, power supply) 4-pin connector CN2
RS-232/422/485 serial port connector 14-pin box header CN18
Serial ATA (SATA) drive connector 7-pin SATA CN26
Serial ATA (SATA) drive connector 7-pin SATA CN27
TTL LCD con nector 40-pin crimp CN10
USB connector 8-pin header CN12
