User Manual

IOWA-LX-600 Half-size CPU Card
Page 91
Phoenix - AwardBIOS CMOS Setup Utility
IT8888 ISA Decode IO
Decode I/O Space 0 [Enabled]
Decode I/O Speed 0 [Medium Speed]
Decode I/O Addr. 0 [15:0] [0100]
Decode I/O Size 0 [64 Bytes]
Decode I/O Space 1 [Enabled]
Decode I/O Speed 1 [Medium Speed]
Decode I/O Addr. 1 [15:0] [0180]
Decode I/O Size 1 [64 Bytes]
Decode I/O Space 2 [Enabled]
Decode I/O Speed 2 [Medium Speed]
Decode I/O Addr. 2 [15:0] [0200]
Decode I/O Size 2 [128 Bytes]
Decode I/O Space 3 [Enabled]
Decode I/O Speed 3 [Medium Speed]
Decode I/O Addr. 3 [15:0] [0340]
Decode I/O Size 3 [32 Bytes]
Decode I/O Space 4 [Enabled]
Decode I/O Speed 4 [Medium Speed]
Decode I/O Addr. 4 [15:0] [0300]
Decode I/O Size 4 [64 Bytes]
Decode I/O Space 5 [Enabled]
Decode I/O Speed 5 [Medium Speed]
Decode I/O Addr. 5 [15:0] [0A79]
Decode I/O Size 5 [ 1 Bytes]
Item Help
Menu Level >
 ↑ ↓:Move Enter:Select +/-/PU/PD:Value F10:Save Esc:Exit F1:General Help
F5=Previous Values F6:Fail-Safe Defaults F7 Optimized Defaults
BIOS Menu 8: IT8888 ISA Decode IO
 Decode IO Space x [Enabled]
Use the Decode IO Space x option to enable or disable the decoding of a particular IO
space.

Disabled
IO space decoding is disabled

Enabled
(Default) IO space decoding is enabled and the options below a re
accessible
 Decode IO Speed x [Medi um Speed]
Use the Decode IO Space x option to enable or disable the decoding of a particular IO
space.
