eKINO-945GSE Motherboard
Page 63
5.2 Installation Considerations
NOTE:
The following installation notices and installation considerations should
be read and understood before the eKINO-945GSE is installed. All
installation notices pertaining to the installation of the eKINO-945GSE
should be strictly adhered to. Failing to adhere to these precautions
may lead to severe damage of the eKINO-945GSE and injury to the
person installing the motherboard.
5.2.1 Installation Notices
WARNING:
The installation instructions described in this manual should be
carefully followed in order to prevent damage to the eKINO-945GSE,
eKINO-945GSE components and injury to the user.
Before and during the installation please DO the following:
Read the user manual:
o The user manual provides a complete description of the eKINO-945GSE
installation instructions and configuration options.
Wear an electrostatic discharge cuff (ESD):
o Electronic components are easily damaged by ESD. Wearing an ESD cuff
removes ESD from the body and helps prevent ESD damage.
Place the eKINO-945GSE on an antistatic pad:
o When installing or configuring the motherboard, place it on an antistatic
pad. This helps to prevent potential ESD damage.
Turn all power to the eKINO-945GSE off:
o When working with the eKINO-945GSE, make sure that it is disconnected
from all power supplies and that no electricity is being fed into the system.
