4.1.2 Internal Peripheral Interface Connectors
8Table 4-1 shows a list of the peripheral interface connectors on the eKINO-945GSE.
Detailed descriptions of these connectors can be found below.
Connector Type Label
Battery connector 2-pin box header BT1
CompactFlash® slot CompactFlash® slot J2
Digital I/O connector 10-pin header DIO1
Fan connector 3-pin wafer J1
Front panel connector 14-pin header F_PANEL1
IDE connector 44-pin box header IDE1
Infrared connector 5-pin header IR1
Keyboard/Mouse connector 6-pin box header MS/KB1
LCD backlight inverter connector 5-pin box header INVERTER1
LED connector 6-pin connector J3
LVDS connector 30-pin crimp LVDS1
MCU LAN connector 8-pin box header J10
PCIe Mini slot PCIe Mini connector MINI_PCIE1
Power connectors Power connectors PWR1
CN2
SATA drive connectors SATA port SATA1
SATA2
SATA power connectors 4-pin box header PW1
PW2
Serial port connectors (RS-232) 10-pin header COM3
COM4
Serial port connector (RS-422/485) 6-pin header JP2
SO-DIMM socket SO-DIMM socket DIMM1
SPDIF connector 5-pin header SPDIF1
