eKINO-945GSE Motherboard
Page 110
6.3.5 Power Configuration
The Power Configuration menu (9BIOS Menu 8) configures the Advanced Configuration
and Power Interface (ACPI) and Power Management (APM) options.
BIOS Menu 8: Power Configuration
6.3.5.1 ACPI Configuration
The ACPI Configuration menu (BIOS Menu 9) configures the Advanced Configuration
and Power Interface (ACPI) and Power Management (APM) options.
