Manual

eKINO-945GSE Motherboard
Page 107
Î
Full On Mode DEFAULT
Fan is on all the time
Î
Automatic mode
Fan is off when the temperature is low
enough. Parameters must be set by the
user.
Î
PWM Manual mode
Pulse width modulation set manually
When the CPU FAN Mode Setting option is in the Automatic Mode, the following
parameters can be set.
 CPU Temp. Limit of OFF
 CPU Temp. Limit of Start
 CPU Fan Start PWM
 Slope PWM 1
When the CPU FAN Mode Setting option is in the PWM Manual Mode, the following
parameters can be set.
 CPU Fan PWM control
Î CPU Temp. Limit of OFF [000]
WARNING:
Setting this value too high may cause the fan to stop when the CPU is
at a high temperature and therefore cause the system to be damaged.
The CPU Temp. Limit of OFF option can only be set if the CPU FAN Mode Setting
option is set to Automatic Mode. Use the CPU Temp. Limit of OFF option to select the
CPU temperature at which the cooling fan should automatically turn off. To select a value,
select the CPU Temp. Limit of OFF option and enter a decimal number between 000 and
127. The temperature range is specified below.
 Minimum Value: 0°C
 Maximum Value: 127°C
