eKINO-945GSE Motherboard
Page 104
Normal Default
IrDA
ASK IR
Î Serial Port2 Address [2F8/IRQ3]
Use the Serial Port2 Address option to select the I/O and IRQ addresses.
Î
Disabled
No base address is assigned to Serial Port 2
Î
2F8/IRQ3 DEFAULT
I/O port address is 3F8 and the interrupt address is IRQ3
Î
3E8/IRQ4
I/O port address is 3E8 and the interrupt address is IRQ4
Î
2E8/IRQ3
I/O port address is 2E8 and the interrupt address is IRQ3
Î Serial Port2 Mode [Normal]
Use the Serial Port2 Mode option to select the transmitting and receiving mode.
Normal Default
IrDA
ASK IR
Î Serial Port3 Address [3E8]
Use the Serial Port 3 Address option to set the I/O address.
Î
Disabled
No I/O address assigned
Î
3E8 DEFAULT
The assigned I/O address is 3E8
Î
2E8
The assigned I/O address is 2E8
Î
2F0
The assigned I/O address is 2F0
Î
2E0
The assigned I/O address is 2E0
Î Serial Port 3 IRQ [11]
Use the Serial Port 3 IRQ option selects the IRQ.
11 Default
