AUPS Series Power Module User Manual
Page 19
the panel PC. Secure the mounting bracket to the panel PC with four retention
screws (
Figure 3-4).
Figure 3-4: Mounting Bracket Installation
Step 2: Place the AUPS Series onto the mounting bracket. Secure the AUPS Series
to the bracket with three retention screws, one on the top panel and one on each
side panel (
Figure 3-5).
Figure 3-5: Mounting the AUPS Series
