AUPS Series Power Module User Manual
Page 14
1
USB Type A to mini-B cable
1
Screw
kit
2
Wall mount bracket
1
Utility software CD
Table 2-1: Package List Con
tents
1
...
...
22
23
24
25
26
...
...
55
