AFL2-12A-D525 Series Panel PC
Page 96
Î
Disabled
DMIC function disabled
Î
Enabled DEFAULT
DMIC function enabled
Î BT Function [Enabled]
Use the BT Function option to enable or disable the BT function.
Î
Disabled
BT function disabled
Î
Enabled DEFAULT
BT function enabled
Î AutoDimming Function [Enabled]
Use the AutoDimming Function option to enable or disable the auto dimming function.
Î
Disabled
Auto dimming function disabled
Î
Enabled DEFAULT
Auto dimming function enabled
6.5.3 Intel IGD SWSCI OpRegion
Use the Intel IGD SWSCI OpRegion menu (BIOS Menu 15) to configure the video device
connected to the system.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
Intel IGD SWSCI OpRegion Configuration
DVMT Mode Select [DVMT Mode]
DVMT/FIXED Memory [Maximum]
IGD – Boot Type [CRT + LFP]
LCD Panel Type [1024x768 18bit]
Panel ID Resolution 640x480 18bit
Select DVMT/FIXED Mode
Memory size used by
Internal Graphics Device
---------------------
ÅÆ
: Select Screen
↑ ↓: Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 15: Intel IGD SWSCI OpRegion
