Î
Auto DEFAULT
The serial port IO port address and interrupt address
are automatically detected.
Î
IO=3E8h;
IRQ=11
Serial Port I/O port address is 3E8h and the interrupt
address is IRQ11
Î
IO=3E8h;
IRQ=10,11
Serial Port I/O port address is 3E8h and the interrupt
address is IRQ10,11
Î
IO=2E8h;
IRQ=10, 11
Serial Port I/O port address is 2E8h and the interrupt
address is IRQ10,11
6.3.5.1.3 Serial Port 5 Configuration
Î Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Î
Disabled
Disable the serial port
Î
Enabled DEFAULT
Enable the serial port
Î Select Serial Mode [Auto]
Use the Select Serial Mode option to set the serial port communication mode.
Î
RS422
Serial port mode is set to RS-422 communications.
Î
RS485
Serial port mode is set to RS-485 communications.
Î
Auto DEFAULT
Serial port mode is set to Auto.
Î Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.
Î
Auto DEFAULT
The serial port IO port address and interrupt address
are automatically detected.
