6.3.3 IDE Configuration
Use the IDE Configuration menu (BIOS Menu 5) to change and/or set the configuration
of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
PATA Master Not Present
PATA Slave Not Present
SATA Port0 KINGSTON SS100 (16.0G
SATA Port1 Not Present
SATA Port2 Not Present
SATA Port3 Not Present
ATA/IDE Configuration [Enhanced]
Configure SATA as [IDE]
Select ATA/IDE
Configuration
---------------------
ÅÆ : Select Screen
↑ ↓: Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 5: IDE Configuration
Î ATA/IDE Configuration [Enhanced]
Use the ATA/IDE Configuration option to configure the SATA controller.
Î
Disabled
Disables the on-board SATA controller.
Î
Compatible DEFAULT
Configures the on-board SATA controller to be in
compatible mode. In this mode, a SATA channel will
replace one of the IDE channels. This mode supports
up to 6 storage devices.
Î
Enhanced
Configures the on-board SATA controller to be in
Enhanced mode. In this mode, IDE channels and SATA
channels are separated.
Î Configure SATA as [IDE]
Use the SATA Mode option to configure SATA devices as normal IDE devices.
