1.4 System Specifications
The technical specifications for the AFOLUX AFL-xxA-N270 series systems are listed in
Table 1-2.
Specification AFL-07A-N270 AFL-08AH-N270 AFL-10A-N270 AFL-12A-N270
LCD Size 7” 8.4” 10.4” 12.1”
Max. Resolution 800 x 480 800 x 600 800 x 600 1024 x 768
Contrast Ratio 400:1 600:1 500:1 500:1
Brightness (cd/m
2
) 350 450 400 400
LCD Color 262K 262K 262K 262K
Pixel Pitch (H x V)
(mm)
0.1905 x 0.1905
0.213 x 0.213 0.264 x 0.264 0.240 x 0.240
Viewing Angle (H-V) 140 / 100 140 / 120 120 / 100 120 / 100
Backlight MTBF 50,000 hours 50,000 hours 50,000 hours 60,000 hours
SBC Model AFLMB-945GSE
CPU 1.6 GHz Intel® Atom™ N270 processor
GMCH Intel® 945GSE
Memory One 1.0 GB 533 MHz DDR2 SDRAM SO-DIMM pre-installed
(Supports up to 2 GB 533/400 MHz DDR2 SDRAM)
SSD CF Type II slot
Watchdog Timer Software Programmable supports 1 sec. ~ 255 sec. system reset
Audio AMP 1.5 W + AMP 1.5 W (built-in stereo speakers)
1 x PCIe mini card (wireless LAN 802.11 b/g module) Expansion
1 x Bluetooth module (USB interface, Bluetooth v 2.0)
HDD Drive Bay 1 x 2.5” SATA HDD bay or HSDPA module (AFL-12A-N270 Only)
Construction Material ABS + PC plastic front frame
Mounting Panel
Wall
Stand
Arm (VESA 75 mm x 75 mm or 100 mm x 100 mm)
Front Panel Color Gray 7539U
Dimensions (W x H x D)
(mm)
226 x 140 x 40.18
234 x 184 x 41.09 276 x 227 x 50.7 304 x 246 x 49.5
