AFL-xxA-N270 Series Panel PC
Page 130
Figure 7-40: Wireless Driver Configuration Tool Options
Step 6: Select configuration tool in
Figure 7-40 and click NEXT to continue.
Step 7: The Wireless Mode Options window in
Figure 7-41 appears.
Figure 7-41: Wireless Mode Select Window
Step 8: Click N
EXT in Figure 7-41.
