AFL-xxA-N270 Series Panel PC
Page 99
DVMT Mode Select [DVMT Mode]
Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology
(DVMT) operating mode.
Fixed Mode
A fixed portion of graphics memory is reserved as
graphics memory.
DVMT Mode D
EFAULT
Graphics memory is dynamically allocated
according to the system and graphics needs.
Combo Mode
A fixed portion of graphics memory is reserved as
graphics memory. If more memory is needed,
graphics memory is dynamically allocated
according to the system and graphics needs.
DVMT/FIXED Memory
Use the DVMT/FIXED Memory option to specify the maximum amount of memory that
can be allocated as graphics memory. This option can only be configured for if DVMT
Mode or Fixed Mode is selected in the DVMT Mode Select option. If Combo Mode is
selected, the maximum amount of graphics memory is 128MB. Configuration options are
listed below.
64MB
128MB D
EFAULT
Maximum DVMT
Boot Display Device [LFP]
Use the Boot Display Device option to select the display device used by the system
when it boots. Configuration options are listed below.
CRT
LFP D
EFAULT
