5.5.1 Host Bridge Configuration
Use the Host Bridge menu (BIOS Menu 15) to configure the Host Bridge chipset.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
>Intel IGD Configuration
******* Memory Information *******
Memory Frequency 800 MHz(DDR3)
Total Memory 2048 MB
DIMM#1 2048 MB
Select which graphics
c
ontroller to use as the
primary boot device.
---------------------
ÅÆ : Select Screen
↑ ↓: Select Item
Enter Select
+ - Change Opt.
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 15: Host Bridge Configuration
5.5.1.1 Intel IGD Configuration
Use the Intel IGD Configuration menu (BIOS Menu 16) to configure the video device
connected to the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Intel IGD Configuration
IGD - Boot Type [VBIOS Default]
LVDS Panel Type [800x480 LVDS]
Backlight Control [Inverted]
Fixed Graphics Memory Size [128MB]
C
onfigure Fixed Graphics
Memory Size
---------------------
ÅÆ : Select Screen
↑ ↓: Select Item
Enter Select
+/-: Change Opt.
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 16: Intel IGD Configuration
