AFL-xxA-N26 Series Panel PC
Page 84
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU_FAN1 Smart Fan control [Auto Duty-Cycle Mode]
CPU Temperature 1 60
CPU Temperature 2 50
CPU Temperature 3 40
CPU Temperature 4 30
SYS_FAN1 Smart Fan control [Auto Duty-Cycle Mode]
System Temperature 1 60
System Temperature 1 50
System Temperature 1 40
System Temperature 1 30
Smart Fan Mode Select
(Reference System
Temperature)
---------------------
ÅÆ
: Select Screen
↑ ↓: Select Item
Enter Select
+ - Change Opt.
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 11: Smart Fan Mode Configuration
Î CPU_FAN1 Smart Fan control [Auto Duty-Cycle Mode]
Use the CPU_FAN1 Smart Fan control option to configure the CPU Smart Fan.
Î
Manual Duty Mode
The fan spins at the speed set in Manual by Duty
Cycle settings
Î
Auto Duty-Cycle
Mode
DEFAULT
The fan adjusts its speed using Auto by
Duty-Cycle settings
Î CPU Temperature n
Use the + or – key to change the CPU Temperature n value. Enter a decimal number
between 1 and 100.
Î SYS_FAN1 Smart Fan control [Auto Duty-Cycle Mode]
Use the SYS_FAN1 Smart Fan control option to configure the System Smart Fan.
Î
Manual Duty Mode
The fan spins at the speed set in Manual by Duty
Cycle settings
