AFL-xxA-N26 Series Panel PC
Page 83
Î
IO=250h;
IRQ=10,11
Serial Port I/O port address is 250h and the
interrupt address is IRQ10, 11
Î
IO=2E0h;
IRQ=10,11
Serial Port I/O port address is 2E0h and the
interrupt address is IRQ10, 11
5.3.7 F81866 H/W Monitor
The F81866 H/W Monitor menu (BIOS Menu 10) shows the operating temperature, fan
speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
>Smart Fan Mode Configuration
System Temperature : +35 C
Smart Fan Mode Select
---------------------
ÅÆ
: Select Screen
↑ ↓: Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 10: Hardware Health Configuration
Î Hardware Health Status
The following system parameters and values is shown. The system parameter that is
monitored is:
System Temperature
5.3.7.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 11) to configure smart
fan temperature and speed settings.
