Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Configuration
Processor Type Intel(R) Atom(TM)
CPU N2600 @ 1.60GHz
EMT64 Supported
Processor Speed 1600 MHz
System Bus Speed 400 MHz
Ratio Status 16
Actual Ratio 16
System Bus Speed 400 MHz
Processor Stepping 30661
Microcode Revision 269
L1 Cache RAM 2x56 k
L2 Cache RAM 2x512 k
Processor Core Dual
Hyper-Threading Supported
Hyper-threading [Enabled]
Enabled for Windows XP
and Linux (OS optimized
for Hyper-Threading
T
echnology and Disabled
for other OS (OS not
optimized for
Hyper-Threading
Technology).
----------------------
ÅÆ : Select Screen
↑ ↓: Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 5: CPU Configuration
The CPU Configuration menu lists the following CPU details:
 Processor Type: Lists the brand name of the CPU being used
 EMT64: Indicates if EM64T is supported by the CPU.
 Processor Speed: Lists the CPU processing speed
 System Bus Speed: Lists the system bus speed
 Ratio Status: Lists the ratio status
 Actual Ratio: Lists the actual ratio
 Processor Stepping: Lists the CPU processing stepping
 Microcode Revision: Lists the microcode revision
 L1 Cache RAM: Lists the amount of storage space on the L1 Cache
 L2 Cache RAM: Lists the amount of storage space on the L2 Cache
Processor Core: Lists the number of the processor cores
 Hyper-Threading: Indicates if Hyper-Threading is supported by the CPU.
