AFL-xxA-N26 Series Panel PC
Page 43
Description Label Type
Clear CMOS JP2 3-pin header
COM3 Pin 9 setting JP5 6-pin header
RS-232/422/485 select JP4 12-pin header
Table 3-1: Jumpers
3.8.1 Access the Jumpers
To access the jumpers, remove the back cover and the aluminum cover. To remove the
covers, please refer to Section
3.4.
3.8.2 Preconfigured Jumpers
WARNING:
Do not change the settings on the jumpers in described here. Doing so
may disable or damage the system.
The following jumpers are preconfigured for the AFL-xxA-N26. Users should no change
these jumpers (
Table 3-2). The jumper settings of the preconfigured jumpers are listed in
Chapter
7 for reference.
Jumper Name Label Type
Backlight voltage selection J_BL1 3-pin header
Inverter ADJ power selection JP6 3-pin header
Inverter power selection JP1 6-pin header
LVDS voltage selection J_VLVDS1 3-pin header
Touchscreen selection J1 4-pin header
Table 3-2: Preconfigured Jumpers
