AFL-xxA-N26 Series Panel PC
Page 26
VESA 100 mm x 100 mm (AFL-10A-N26 and AFL-12A-N26 only)
Front Panel Color Gray 7539U
Dimensions (W x H x D)
(mm)
226 x 140 x 41 234 x 184 x 42 276 x 222 x 51 304 x 246 x 50
Operation Temperature -10ºC ~ 50ºC
Storage Temperature -20ºC ~ 60ºC
Humidity 10% ~ 95% (non-condensing)
Net weight 0.6 kg 0.8 kg 1.4 kg 1.8 kg
IP level (front panel) IP 64
Touch Screen Resistive Type 4-wire
(touch controller is on board)
Resistive Type 5-wire
(touch controller is on board)
Power Requirement 9 V ~ 28 V DC 9 V ~ 28 V DC
36 W 60 W
Input: 90 VAC ~ 264 VAC @ 50 Hz / 60 Hz
Power Adapter
Output: 12 V DC
I/O Ports and Switches 1 x 9 V ~ 28 V DC input jack
1 x Audio line-out connector
1 x RS-232 COM port connector (RJ-45)
1 x RS-232/422/485 COM port connector (DB-9)
2 x RJ-45 for LAN
2 x USB 2.0 ports (four USB 2.0 ports on the AFL-12A-N26 model)
1 x VGA connector
1 x Power button
1 x Reset button
1 x AT/ATX power switch
Table 1-2: AFL-xxA-N26 Series System Specifications
