1.4 Internal Overview
The AFOLUX AFL-xxA-N26 has the following components installed internally:
1 x Motherboard
1 x 2.0 GB 1333 MHz/1066 MHz DDR3 SDRAM SO-DIMM
1 x Wireless module
1.5 System Specifications
The technical specifications for the AFOLUX AFL-xxA-N26 series systems are listed in
Table 1-2.
Specification AFL-W07A-N26 AFL-08A-N26 AFL-10A-N26 AFL-12A-N26
LCD Size Wide 7” 8.4” 10.4” 12.1”
Max. Resolution 800 x 480 800 x 600 800 x 600 1024 x 768
Contrast Ratio 400:1 600:1 700:1 700:1
Brightness (cd/m
2
) 500 450 400 500
LCD Color 262K 262K 262K 262K
Pixel Pitch (H x V) (mm) 0.0635 x 0.1905
0.213 x 0.213 0.264 x 0.264 0.3057 x 0.3057
Viewing Angle (H-V) 140 / 110 160 / 140 160 / 140 160 / 160
Backlight LED backlight LED backlight LED backlight LED backlight
Backlight MTBF 50,000 hrs 50,000 hrs 50,000 hrs 50,000 hrs
CPU 1.6 GHz Intel® Atom™ dual-core processor N2600
Chipset Intel® NM10 Express Chipset
Memory One 2.0 GB 1333 MHz/1066 MHz DDR3 SDRAM SO-DIMM pre-installed
(system max. 2 GB)
Ethernet Controller Two Realtek RTL8111E PCIe GbE controllers with ASF 2.0 support
Wireless Wireless LAN 802.11 b/g/n 2T2R module (PCIe Mini card)
Watchdog Timer Software Programmable supports 1 sec. ~ 255 sec. system reset
Audio AMP 2 W + AMP 2 W (built-in stereo speakers)
Storage 1 x PCIe Mini card slot for mSATA SSD
1 x 2.5” SATA HDD bay (AFL-12A-N26 only)
Construction Material ABS + PC plastic front frame
Mounting Panel, Wall, Rack, Stand, Arm
VESA 75 mm x 75 mm or
