7.3.6 Reset Button Connector (RST1)
7.3.7 USB 2.0 Connectors (USB4)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +5Vsus 5 +5Vsus
2 D4F- 6 D5F-
3 D4F+ 7 D5F+
4 GND 8 GND
Table 7-36: USB 2.0 Connectors (USB4) Pinouts
7.3.8 VGA Connector (VGA1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 RED 2 GREEN
3 BLUE 4 N/A
5 GND 6 CRT_PLUG
7 GND 8 GND
9 +5V 10 GND
11 N/A 12 DDCDA
13 HSYNC 14 VSYNC
15 DDCLK
Table 7-37: VGA Connector (VGA1) Pinouts
PIN NO. DESCRIPTION
1 RST_SW
2 GND
3 GND
4 GND
Table 7-35: Reset Button Connector (RST1) Pinouts
