AFL-xxA-N26 Series Panel PC
Page 130
17 TFT_B2 37 GND
18 TFT_B1 38 DOTCLK
19 TFT_B0 39 GND
20 GND 40 GND
Table 7-22: TTL Panel Connector (CN6) Pinouts
7.2.22 USB Connector (USB1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +5Vsus 2 GND
3 D0F- 4 D1F+
5 D0F+ 6 D1F-
7 GND 8 +5Vsus
2 8
y y y y
y y y y
1 7
Table 7-23: USB Connector (USB1) Pinouts
7.2.23 USB Connector (USB2)
PIN NO. DESCRIPTION
1 +5Vsus
2 D2F-
3 D2F+
4 GND
Table 7-24: USB Connector (USB2) Pinouts
