AFL-xxA-N26 Series Panel PC
Page 128
7.2.16 Power LED Connector (PW_LED1)
7.2.17 Power Button Connector (PW_BTN1)
7.2.18 SATA Power Connector (SATA_PWR1)
7.2.19 SATA Connector (SATA1)
PIN NO. DESCRIPTION
1 PW_LED +5V
2 GND
3 SUS PW LED +5V
Table 7-17: Power LED Connector (PW_LED1) Pinouts
PIN NO. DESCRIPTION
1 PW_BN
2 GND
Table 7-18: Power Button Connector (PW_BTN1) Pinouts
PIN NO. DESCRIPTION
1 +5V
2 GND
Table 7-19: SATA Power Connector (SATA_PWR1) Pinouts
PIN NO. DESCRIPTION
1 GND
2 STXP_0
3 STXN_0
4 GND
5 SRXN_0
6 SRXP_0
7 GND
Table 7-20: SATA Connector (SATA1) Pinouts
